DAS Audio Altea-Duo-20A

Let the show begin

Whether you need sound reinforcement for a concert hall, theater, house of worship or DJ studio, let our team of professionals help you find the audio equipment that will ensure the success of your event

.

Although the Das Audio company made us wait a long time for post solutions, we can finally offer you two models to choose from: ALTEA-DUO-10A and ALTEA-DUO-20A. You must see and test them.

The Altea DUO-10A is a 3-way portable loudspeaker designed for mobile applications, from corporate events, celebrations and conferences to live music and more. Its two-channel Class D amplifier and universal 1000W peak power supply provide power and dynamics. The DSP includes DAScontrol technology with an LCD display and a dial to select multiple acoustic modes (presets) depending on how the system is used, as well as access to other configurable options in the system menu.

The DSP includes two independent mic/line inputs with appropriate volume settings and a third instrument input for connecting instruments. Audio can be streamed wirelessly from mobile devices and the entire system can be controlled via the DASlink GM app.

The system is based on 2x 10-inch 10MG4 drivers specially developed to reproduce low frequencies with very low distortion levels. To reproduce the mid to high frequencies, the top system includes four x 3-inch 3PN16 neodymium magnet drivers and an M27N neodymium compression driver coupled to a 100º x 50º horn. The horizontal directional control of the system provided by the horn is highly uniform throughout the high frequency spectrum (f>1000Hz) and the pressure transducer ensures that the highs are precise.

App control

As with the Altea 700 systems, for these portable column systems
 there is also the DASlink GM App, offering the possibility
 wireless audio streaming, control, monitoring and grouping
 systems from mobile devices.

Powerful DSP Processor

 The DSP incorporates technologies found in the Altea and Vantec series, such as DAScontrol with an LCD display and rotary knob for selecting acoustic settings and accessing
 other configurable options in the menu, such as delay or volume control
 subwoofer..





Unique possibilities

The mixer features two independent mic/line inputs with gain settings and a third instrument input for connecting keyboards, bass guitars or guitars. It also includes a cable output connection to share your audio mix and add more Altea-DUO systems to your setup

Technical Specifications;

• Lightweight and comfortable three-way active PA
• Speakers: bass 2x10''-10mg4/broadband: 4 x 3''-3PN16/treble: 1x driver M27N
• frequency response; 37Hz-20kHz (-6dB)
• Class D amplifier
• Power ;1000w/program 2000w Peak
• (500w-bass/400w-broadband/100w-treble)
• Max SPL;127Db
• directionality; 100°H x 50ºV (User Rotatable)
• Control: DAScontrol™/DASlink GM™
• Built-in DSP Sound Processor: Flat Indoor, Flat Outdoor, Music, DJ, Vocal
• Output Connectors: 2 x XLR/TRS Combo Jack - Mic/Line 1 x Stereo/Bluetooth 1 x 1/4 TRS HI-Z Instrument
• AUX Input: 1 x 3.5mm Mini Jack
• Audio Thru connector: 1x XLR-F
• Housing: Polypropylene .
• Color; white

• Dimensions; Subwoofer200x360x445mm

• Weight: 39kg/packing 42kg
